2
|
3944201P
|
Cord Wrap
|
|
3
|
43434031
|
Hose Assembly Comp.
|
|
4
|
36433111 +
|
Hose Holder - Early Models
|
| |
36433137
|
Hose Holder - Late Models - see note # 1
|
|
5
|
40201149
|
Handle Hardware
|
|
6
|
36433120
|
Wand/Hose Holder - ABE
|
|
7
|
21447242
|
Screw Self Tapping
|
|
8
|
23149002
|
Screw - U5463-960,
|
|
9
|
43457024
|
Hose Door Assembly
|
|
10
|
47823003
|
EOF Mic / Duct Assembly
|
|
11
|
31178017
|
Hose Connector Gasket
|
|
12
|
34311004
|
Wire Opening Seal
|
|
13
|
43431005
|
Angled Hose Connection Assem.
|
|
14
|
27482230
|
Strain Relief
|
|
15
|
46383322
|
Cord -35' -3/1 6" Terminal
|
| |
46383334
|
Cord - 35' - 1/4" Terminal (See note 3)
|
|
16
|
37255011
|
Bag Housing - Dlx. - ABE
|
|
17
|
43576188
|
Motor Assembly
|
| |
43566016
|
Motor Suction Fan
|
| |
33426001
|
Fan Nut
|
|
18
|
36322035
|
Motor Mount - Large
|
|
19
|
41311017
|
Motor Brush Assembly (2)
|
|
20
|
47534027
|
Thermal Protector - 3/16" Terminal
|
| |
28382087
|
Thermal Prot. - 1/4" Terminal (See note 3)
|
| |
51873001
|
Thermal Protector Label
|
|
21
|
|
Not Applicable
|
|
22
|
37196009
|
Motor Cover
|
|
23
|
21447230
|
Screw Self Tapping
|
|
24
|
21447228
|
Screw Self Tapping
|
|
25
|
39383107
|
Lens - CP
|
|
26
|
27352030
|
Snap-In Lens - Red
|
|
27
|
27352031
|
Snap-In Lens - Green
|
|
28
|
42258001
|
EOF Cover - models w/ red and green light
|
| |
42258002
|
EDF Cover - models w/ red, green and
|
|
29
|
46851031
|
EOF PCB - w/ red and green lights
|
| |
46851032
|
EDF PCB - w/ red, green, and amber lights
|
|
30
|
27313101
|
Dirt Finder Lamp
|
|
31
|
47173024
|
Wiring Harness - 3/16" Terminals
|
| |
47173028
|
Wiring Harn. - 1/4" Terminals (See note 3)
|
|
32
|
21447072
|
Screw Self Tapping
|
|
33
|
42255053
|
Bag Door - ABY - (Inc.items
34, 35, 36 )
|
| |
42255063
|
Bag Door - ACL - U5461-900, U5463-900 (Inc. items 34, 36)
|
| |
42255053
|
Bag Door - ABY - (Inc. items 34, 36)
|
| |
42255053
|
Bag Door - ABY - Common - U5443-900 (Inc. items 34, 36)
|
| |
42255082
|
Bag Door - ACF - (Inc. items 34, 36)
|
| |
42255088
|
Bag Door - MU - (Inc. items 34, 36)
|
| |
42255098
|
Bag Door - ADK - (Inc. items 34, 36)
|
| |
42255092
|
Bag Door - ADX - U5460-900 (Inc. items 34, 36)Models before June
2001
|
| |
42255096
|
Bag Door - Dark Spruce - U5457-900 (Inc. items 34, 36)
|
| |
42255087
|
Bag Door - ABY - - Models with amber
|
| |
|
performance indicator - no check bag indicate
|
| |
42255075
|
Bag Door - ABY - Models with amber performance
indicator
|
| |
|
- no check bag indicate
|
| |
42255086
|
Bag Door - AG - U5475-900 - Models with amber performance
indicator
|
| |
|
- no check bag indicate
|
| |
42255100
|
Bag Door - ADX - U5460-900 (Inc. items 34, 36)Models after
June 2001
|
| 34 |
34123050
|
Bag Door Gasket
|
|
35
|
51151010
|
Indicator Assem. (Early Models)
|
|
36
|
38781057
|
Bag Door Gasket
|
|
37
|
27618508
|
Wire Connector
|
|
38
|
36322030
|
Motor Mount - Small
|
|
39
|
34131019
|
Wire Opening Plug
|
|
40
|
27479307
|
Lead Wire Tie
|
|
41
|
38765019
|
Secondary Filter
|
|
42
|
36426034
|
Secondary Filter Retainer
|
|
42
|
36426034
|
Secondary Filter Retainer
|
|
43
|
66655409
|
Protector Tube
|
|
44
|
36426033
|
Filter Holder - ABE
|
|
45
|
38766007
|
Final Filter - 2 layer - U5443-900,
|
| |
40110004
|
Final Filter - 3 layer - (Inc. two filters)
|
